40
AXIS Camera Station - AXIS Camera Station Service Control
AXIS Camera Station Service Control
2N IP Intercom can send changes of virtual ONVIF inputs, this can be used to carry out some action, or to log such an event on side of Axis Camera Station.At first it is needed to set another Action rule in 'Gears' section / Recording and events/ Action rules. To add new Rule on switch click on New. User guide. Read online or download PDF. Axis Communications Camera Station User Manual. Axis Communications Video surveillance systems. Manuals Directory ManualsDir.com - online owner manuals library. USER’S MANUAL. AXIS Camera Station.
AXIS Camera Station Service Control is the application that controls AXIS Camera Station Service. The Service Control is
started when the user logs on to Windows and is located in the system tray. In most installations, the Service Control’s default
settings are sufficient, but in those cases where AXIS Camera Station Server and AXIS Camera Station Client or cameras are
separated by a proxy server then settings will need to be adjusted accordingly.
The system tray icon will display service changes, e.g. if the service is started
or stopped
. There are three ways to
open the service control; double-click the icon in the system tray, right-click and select
Open AXIS Camera Station Service
Control from the pop-up menu or from Windows Start > All Programs > AXIS Camera Station 3 > AXIS Camera Station Tools
> Service Control.
In addition to modifying the server settings, the AXIS Camera Station Server Control allows you to start, stop and restart the
server. See also AXIS Camera Station Service Administration, on page 43.
Modify server settings
To change service settings, check the box Modify server settings.
Click
Restore Default Settings to restore the default values for the server, streaming ports and proxy settings.
Server settings
Under
Server settings enter the ports the server will use to communicate with the clients. The streaming port is used for video
streaming, for example sending live video or playback from the server to the client. If there is a NAT or proxy between the
server and clients, the ports must be configured to let communication pass through.
Note: A server port number must lie between 1024-65534
Once satisfied with the changes click
Save. You will be prompted to restart the service for the changes to take effect.
You can have four active simultaneously, and most of the effects are split across dials labeled “FX1,” “2” and “3.” The effects can be combined with amp models, and you have 128 user presets to store your creations in (although by connecting to a computer you can effectively extend this to the limits of your hard drive). Five of these have fairly fixed functions, with two for selecting a bank of presets (when you’re in “Preset Mode”) or scrolling to a specific preset, a “Mode” switch, one for activating and deactivating the optional effects loop and the other for tapping out a tempo for timing-dependent effects. There are also 256 ready-designed presets on the HD400, too.There are plenty of footswitches on the POD HD400, with nine in total allowing for sufficient hands-free operation to suit most players. The higher-end HD500 actually has the same number of effects, which is a big bonus for the HD400, because you don’t lose out on possible effects by opting for the smaller pedal. Line 6 pod hd 400 user manual.
45
AXIS Camera Station - Troubleshooting
The Graphics card driver is more than
3/12 months old. (cont)
In Windows Vista
1. Select Start
2. Enter dxdiag in the Start Search field
3. If a prompt appears for the Diagnostic Tool, click Yes
4. Select the Display tab. The name of the Graphics card appears under Device
To download the latest driver you need to visit the graphics card manufacturer's web
site. Some of the more common ones are
• nVidia - www.nvidia.com
• ATI - www.ati.com
• S3 - http://www.s3graphics.com
To upgrade the graphics card drivers on your computer:
1. Download the driver from the manufacturers web site to your hard drive
2. Make sure that there are no other programs running on your computer.
3. Uninstall the existing drivers
4. Run the installer and follow the wizard to install necessary files
5. Reboot to activate the change
Live View
No image from camera
Proper decoders must be installed for MPEG-4 and H.264 video formats. In licensed
mode, click on the link provided where the camera’s Live View should be to launch the
installation of codecs. In AXIS Camera Station One or Demo mode, download the proper
codecs from the camera’s Live View page.
Repeated error message 'Media Failed' Try reducing the load to the CPU by modifying the Live View Settings for each camera
under Configuration. Reduce the resolution, increase the compression setting and
lower the frame rate.
Check that your computer is not running low on memory.
Logon/connecting to server
User is not authorized to login on
server!
• Check that the user name and password are valid
• Check that the user has access rights to AXIS Camera Station Server
• If AXIS Camera Station client is running on Microsoft Vista and the user has not
been added to the server, but is a member of the local administrators group on
the server, the client can be started by right-clicking on the shortcut and
selecting Run As Administrator. To avoid this, make sure that the user is added
to AXIS Camera Station server using the User Permissions dialog
AXIS Camera Station Server was unable
to verify message security. Please make
sure server and client UTC times are
reasonably synchronized
The clocks in AXIS Camera Station server and client are not synchronized. Adjust the
clock in either the server or client so that they have the same date and time properties.
For more information on setting up time in your computer consult the Window’s help
files.
Connection refused, server is not
accepting any connections.
Check that a NAT/firewall is not blocking a connection to the server
No connection, unable to locate server.
• Check the address and port of the AXIS Camera Station server is correct.
• Check that a NAT/firewall is not blocking a connection to the server
• Check that the server is running. One way is to click on the AXIS Camera Sta-
tion Server icon in the system tray. Check the Server Status at the bottom of
AXIS Camera Station Service Control. If status Shows 'Stopped', click Start.
Failed to connect to server!
• Verify that the computer the server and client are installed on is up to date and
has the latest service packs/patches from Microsoft
• Verify that the network is correctly installed and configured on the server and
client computer(s)
• Verify that no NAT/firewalls are blocking connection between AXIS Camera
Station client and server
Station 5 Spa
Menu items
I can't see the configuration menu
You do not have administrator privileges. Menu items are hidden from users that are
not granted access under User Permissions.
